AVEVA Reports - Case Study

Many companies find themselves in a transition phase between paper based operations to digital based ones. This digitalization process can be slow and painful, but at ACE-ISS we have helped companies with this exact process.

Below we shall summarize our implementation of AVEVA Reports for Operations, while working closely with our customers and patterns.

Challenges

- paper based forms

- aggregation of data by supervisors to some Excel file(s)

- manual data insertion in accounting software

- mistakes are common

- steps are sometimes forgotten

- lack of automated data reading from equipment even when technically possible

- poor insight in equipment downtime and low production

Goals

- eliminate slow paper forms

- reduce errors

- reduce downtime and increase productivity

- replicate existing reports, such as production reports

- have reports that show OEE, downtime count and reasons

Results

Data ingest

- transition to digital forms that enforce standards, allowed values, allowed insertion times and minimize errors

- web reports and forms that can be accessed by people in the company - no need for Client software (except their browser)

- user/group based authorization for reports - restrict report viewing by unauthorized users

- reading data from other sources directly in AVEVA Reports (from WinCC and also from MODBUS TCP)

Reports

- aggregation and calculation reports (for example SUMs, AVERAGEs, MAX, MIN, ON and OFF COUNTER, Electric Meter etc) for Production

- reports calculating and presenting OEE, equipment downtime, availability

- daily creation of CSV reports, to be then imported in accounting software

- allowing users select start and finish data&time for the web report, and providing button to save this report as PDF

- reports can also be automatically sent over email, at designated hours

Database

- one source of truth

- automatic SQL database backups (delta daily and full weekly)
